Laboratory Test Service
Laboratory Test Service


PURACK Laboratory test can provide laboratory testing services for similar processes (cooling crystallization, solid-liquid separation, purification direction) in fine chemical, pharmaceutical, food and other industries. The melt crystallization small plant system is a crystallization and purification device, this device is mainly used to obtain the data or process parameters required for the Pilot laboratory system and industrial production scale.
Laboratory Test


Laboratory test of the main equipment
Verify the process route
Find the optimal process parameters (temperature, pressure, flow rate, time, speed, etc.)
Observe and record the real-time status of the whole process of material
Collect samples of various stages and components
Titration analysis
Other requirements of the small laboratory can be communicated in detail......
Laboratory Test
Equipment parameters (crystallization kettle : 45~100℃) :
  • Equipment volume: ~50L
  •
  • Temperature range: 0~120℃
  •
  • Stirring impeller speed: 0~100rpm
  •
  • Scraper material: PTFE
  •
  • Equipment material: inner tank and stirring paddle SUS316, jacket SUS304
  •
  • Pressure: normal pressure or slightly negative pressure operation
  •
  • Variable frequency speed control
  •
  • Flow: 0~265L/h frequency conversion adjustable
  •
Equipment parameters (washing tower : 45~100℃) :
  • Equipment volume: ~10L
  •
  • Temperature range: 0~100℃
  •
  • Speed of scraper: 0~300rpm
  •
  • Cylinder stroke: 120mm
  •
  • Equipment material: tower body and scraper SUS316L, jacket SUS304
  •
  • Pressure: normal pressure or slightly negative pressure operation
  •
  • Variable frequency speed control
  •
  •  Flow: 0~265L/h frequency conversion adjustable
  •



Are you interested in the PURACK test?
Are you interested in the PURACK test?
ARE YOU INTERESTED IN THE PURACK TEST?
ARE YOU INTERESTED IN THE PURACK TEST?
We look forward to cooperating with you
