Materials : Structural steel,Cast iron.
Stealing : Single mechanical seal,lip seal.
Installation : motor installation footing installation.
Pressure : 1-150bar(depending upon viscosity).
Viscosity : Up to 1000Cps.
Temperature : -18~150℃ (Explain it before selection if the temperature is over 90℃ ).
|
Pump Type |
Single rotation capacity (cc/rev) |
Rated flow rate at |
Maximum speed (rpm) |
Inlet/Outlet dmensicn |
|
FS110 |
1.10 |
1.6 |
1500 |
G 3/8" |
|
FS158 |
1.58 |
2.3 |
1500 |
G1/2" |
|
FS253 |
2.53 |
3.7 |
1500 |
G1/2" |
|
FS348 |
3.48 |
5.2 |
1500 |
G1/2" |
|
FS475 |
4.75 |
7.0 |
1500 |
G1/2" |
|
FS712 |
7.12 |
10.6 |
1500 |
G 1/2" |
|
FS950 |
9.50 |
14.0 |
1500 |
G1/2" |
|
FM142 |
14.2 |
21.0 |
1500 |
G 1/2" |
|
FM214 |
21.4 |
32.0 |
1500 |
G 3/4" |
|
FM320 |
32.0 |
48.0 |
1500 |
G1" |
|
FM481 |
48.1 |
47.0 |
980 |
G1" |
|
FM600 |
60.0 |
58.0 |
980 |
G11/4" |
|
FM800 |
80.0 |
78.0 |
980 |
G11/4" |
|
FL108 |
108.0 |
105.0 |
980 |
G11/2" |
|
FL160 |
160,0 |
115.0 |
720 |
FlangeDN50 |
|
FL240 |
240.0 |
172.0 |
720 |
FlangeDN50 |
