Bimetallic thermometer is a field measuring instrument for measuring medium and low temperature. The bimetallic thermometer can directly measure the temperature of liquid, steam and gas medium in the range of -80 to +500 ℃ in various production processes. The bimetallic thermometer is based on a bimetallic strip circled and bent. When one end is heated and expanded, the needle is driven to rotate, and the working instrument displays the temperature value of the thermal potential.
Type |
Temperature range ℃ |
Precision class |
Protective tube material |
specification |
Mounting fixtures |
|
D |
L |
|||||
WSS-480 |
-80~+40 -80~+40 0~+80 0~100 0~150 0~200 0~400 0~500
|
1.5
|
1Cr18Nl9Ti 304 316
316L
Hastelloy C-276 |
Φ100 |
75 100 150 200 300 400 500 750 1000 |
Unfixed device |
WSS-580 |
Φ150 |
|||||
WSS-481 |
Φ100 |
Movable external thread |
||||
WSS-581 |
Φ150 |
|||||
WSS-482 |
Φ100 |
Internal thread |
||||
WSS-582 |
Φ150 |
|||||
WSS-483 |
Φ100 |
Fixed thread |
||||
WSS-583 |
Φ150 |
|||||
WSS-484 |
Φ100 |
Fixed flange |
||||
WSS-584 |
Φ150 |
|||||
WSS-485 |
Φ100 |
Jacketed thread |
||||
WSS-585 |
Φ150 |
|||||
WSS-486 |
Φ100 |
Sleeve flange |
||||
WSS-586 |
Φ150 |
