Magnetic Liquid Level Meter

Name: Magnetic Liquid Level Meter
Brand: Purack Website
SKU: 00480
Availability: InStock
Rating: 5 (1 reviews)

Model 00480

It applies to the liquid level measurement of liquid medium inside thelcontainer.
Apart from status display, it can also be equipped with functions like teletransmission transmitter and level controller.
Its display is visualized and striking, and the display direction can be changed according to users' requirements.
The measurement range is large, which is not limited to the height of the container.
The display element is completely separated from the measured medium, so it has good leakproofness, both reliable and safe.
It has simple structure, easy to install and maintain.
It is corrosion resistant and blast-proof.

Inquiry

Description

It applies to the liquid level measurement of liquid medium inside thelcontainer. Apart from status display, it can also be equipped with functions like teletransmission transmitter and level controller. Its display is visualized and striking, and the display direction can be changed according to users' requirements. The measurement range is large, which is not limited to the height of the container. The display element is completely separated from the measured medium, so it has good leakproofness, both reliable and safe. It has simple structure, easy to install and maintain, it is corrosion resistant and blast-proof.

Standard Parameter

ITEM	UNIT	MODEL
ITEM	UNIT	MODEL
Measurement range	mm	300-15000
Precision	mm	±10
Medium density		>350kg/m³
Environmental vibration		<25Hz
Medium viscosity		0.4PaS
Material	kw	304, 316, 316L, Ti, PP, PVC, PTFE, Ta, Monel, Hastelloy C276, or other customized materials can be made
Process connecting flange	hp	Standard type HG20592-20635 DN25 PN1.0-PN3.2
Operating temperature	℃	-196-520
Protection grade	kg/cm	Ip66
